8
A
screw
A
screw
Bluetooth module
CF bracket
CF Bluetooth cover
CF & HDD pwb
CF ejector
Bottom is
contact side
CF shield cover
Clinches
FPC-15pin
FPC-35pin
2) Removing four screws and pulling
out FPC cable from the connectors
