08905153A - 17 -
D5-NET
This connector is reserved for future implementation of two-way data sources and communication.
EXPANSION OUT
Connect the CAT-5 Patch Cable from the D5RH ‘EXPANSION OUT’ port to the D5XH ‘EXPANSION
IN’ port as shown. Complete connections for expanded systems are described in the section entitled
Multi-Chassis Connections.
D5RH
D5XH
Cat-5
Ethernet
Patch Cable
Figure 3.5: Expansion Outputs
