ZEN system enables to install, on the waist strap,
XDEEP two-part weight pockets of 2 x 3kg or 2 x 6kg.
The pockets are mounted with bolts to the holes
in the backplate:
OPTIONAL DROPPABLE WEIGHT POCKETS
Fig.4. Mount points of two-part weight pockets
01
In order to install the pockets:
1. Remove the buckle and, if necessary, other elements
from the waist strap (if installed);
2. Fix the pockets on the waist strap by interweaving the
waist strap webbing through proper places in the weight
pockets;
3. With the use of bolts supplied with the pockets, tight-
en the pockets to the plate through holes in the pocket
webbing and do not forget about the washer.
20
06
OPTIONAL TRIM POCKETS
