16
Protective Cover
Protective Cover Rivet
Press down the plastic tip of the rivet
cap about 3 mm, then remove the rivet
bracket to completely remove the rivet.
Press down the plastic tip of the rivet
cap about 3 mm, then remove the rivet
bracket to completely remove the rivet.
Light Board
Light Board Rivet
Warning: Before replacing the LED light board, cut off the electricity to prevent an electric shock.
This replacement should only be carried out by a qualified electrician.
2. Install the light source
Place the light board on the base, and use two new rivets to fix the light board onto
the base. Connect the wiring, then install the protective cover on the light board with
three new rivets to fix the cover onto the base.
cover of the light board, then remove the protective cover of the light board and
unplug the wiring connected to the light board. Finally, uninstall the two rivets from
the light board, and then remove the light board.
EN
To Next Page
