Xiaomi MiniJ - Connecting Water Inlet Hose

a.Dismantle the existing hose-water(in);
e. Turn part B in the direction as shown
in the figure and combine it with part A;
f. Take down the blank plug from the
connector on the other end of T type
hose-water(in);
g. Connect the hose-water(in) connector
with the joint to make a click sound,
automatic combination is completed.
b.Loosen the screw B，turn it to a position
with a distance of 5mm from A;
c.Tighten the hose-water(in) and
the water tap connector.
◆ After installation, turn on the water faucet to check for any leakage. Please use the hose-water(in)
attached with the machine;
◆ Unplug the appliance and turn off the water faucet after use.
1 2
3 4
5
7
9 10
11
12
13
14 15
16
18 19
20 21
22
24 25
26 27
29
30 31
32
33
Connecting the hose-water(in)
