XK DHC-2 A600 - Controller Diagram and Battery Installation

Controller diagram
Transmitter battery installation
-4-
MODE 1(the asia version）
Throttle/Aileron joystick
（presss the 6G/3D Switch）
antenna
power indicator light
power switch
Aileron trim
LED display
Direction trim
elevator trim
elevator trim
throttle/direction joystick
（press down the rudder to change）
MODE 2(European Version）
4pcs”AA”battery
（in additional to buy）
battery
cover
Put the back of the battery cover down and out,
and then install 4 pcs “AA” batteries according
to the positive and negative direction correctly.
finally,close the battery cover.
（(Do not use different types of batteries.）
antenna
power indicator light
power switch
Aileron trim
LED display
direction trim
elevator trim
throttle trim
elevator /joystick
（press down 6G/3D Switch）
throttle/direction joystick
（press the rudder key to change）
