XO CARE A/S YB-904 Ver 1.10
Page 12 of 14
Connect the other end of the cable
CA-033 plug V31 to the liquid pump
V31.
Red wire connects to the wire with the
label.
Connect CA-033 plug S5B to
connector J1 on the cup level sensor.
Connect CA-033 plug s14 to the
connector J1 on the bottle level
sensor on the service door.
