AFTER INSTALLTION UNDER COUNTER, OVERLAY DOOR MUST BE ABLE TO OPEN 90 .
o
overlay panel dimensions xouim1565o & xouim1565op
29 3/8”
MIN.
14 3/4"
FRONT
The panel has a minimum height of 29 3/8” - If making the panel 29 3/8” tall
no further adjustments are needed.
If the panel is taller than 29 3/8”
proceed to pages 18 and 19,
a notch or recess is required.
TOP
MAXIMUM PANEL THICKNESS 3/4”
PANEL MAXIMUM WEIGHT: 20 lbs.
17
3/4"
WATCH THE INSTALLATION
VIDEO ON OUR CHANNEL
https://www.youtube.com/channel/UCT-Ip-dM9hoPydpxZfrZzRA
www.xoappliance.com
