TS3250
PART LIST OF EXPLODED VIEW
NO. DESCRIPTION PART#
1 REAR CABINET 780-10903J040
2 REAR PANEL 808-60835-040
3 MAIN FRAME 863-60139-U00J
4 WASHER 868-20548-00
5
6
7 CRT BRACKET 870-20793-00
8 STAND BY BUTTON BOARD ASSY 667-TS32351-05
9 FRONT CABINET ASSY 611-F50A3-0H1
10 SIDE AV BOARD ASSY 667-TS2950-29
11
12 SPEAKER 384-32108-50
13 STANDBY BUTTON 877-60594-00
14 BUTTON CAP 877-60542-00
15 BUTTON CAP 877-60534-01
16 RUBBER WASHER 868-20123-00
17 SPEAKER BRACKET 870-20693-00
18 LED COLUMN 700-60149-00
19 BUTTON 877-50409-00
20 CRT FIXED BLOCK 868-20319-00
21 COMPONENT NUT 648-30003-00
22 CRT 335-3412M-00U
23 CRT BOARD 667-TSE30-02
24 COVER 808-10537/38-040
25 REAR NAMEPLATE 808-10230-074
