Series EJ, ET, EY, FJ & FR

102002-177 Rev M2

\1020\02177M2.doc 17 Jun 2019

J2 USB CONNECTOR

(See INTERFACE DIAGRAM FIG 10, Table 2, and figure below)

WARNING! Do not make or remove connections to this connector or any other

connector until power is off and the output has discharged.

This serial link implements USB2.1 communication protocol. A 3m (10ft) cable is supplied

with the unit for this purpose.

USB CABLE

SIGNAL NAME

B PINOUT

VBUS

D-

D+

Ground

Table 2 USB B Pinouts
