XPower A-5 - Nozzle and Control Setup

English - 7
Installation and Operation Guide
Nozzle Installation
(Continued)
For model A-12 and A-16:
Connect the nozzle connector in between the nozzle adapter and the nozzle.
For model A-5:
Attach the nozzle onto the air outlet of the hose.
The tapered flow nozzle, straw adapter and the detail brush should be used
together.
• Attach the straw adapter onto the tapered flow nozzle.
• Insert the detail brush inside the other end of the straw adapter.
• Attach the whole set of the nozzles onto the hose.
The standard brush must be attached onto the standard nozzle.
