English - 6
Installation and Operation Guide
(Continued)
Additional Electrical Receptacle (Daisy Chain)
CIRCUIT BREAKER
12A
TOTAL OUTPUT
12 AMPS MAX WITH THIS UNIT OFF
10 AMPS MAX WITH THIS UNIT ON
• Other appliances can be plugged in the
additional electrical receptacles and work
whether the Axial Fan is on or off. However,
the total amperage must be lower than the
amperage instructed. Different models may
have varying instructions.
• If the Axial Fan or the plugged in appliance
stops working, press the RESET BUTTON to
reset the circuit.
120
60
0
ON
180
Timer Switch
• Turn clockwise to set timer for minutes count
down to an automatic stop.
• The timer can be set for up to 180 minutes (3
hours).
• When the timer reaches “0” position, the unit
stops working. On “ON” position, it will work
constantly.
Timer Switch*
* For model X-47ATR only.
