Xray XT2 User Manual

2. REAR TRANSMISSION
3 dots
3 dotsHIGHEST
2 dots
2 dotsHIGHER MIDDLE
1 dots
1 dots
DIFFERENTIAL HEIGHT ADJUSTMENT
INITIAL SETTING INITIAL SETTING
2x 2x
GEAR
RATIO
Internal Gear Ratio = 2.65
12
902310
SH M3x10
OIL
"CLICK"
GRAPHITE GREASE
(HUDY #106210)
GRAPHITE GREASE
(HUDY #106210)
OIL
BEARING OIL
(HUDY #106230)
940612
BB 6x12x4
980320
P 3x20
930308
BB 3x8x4
6x12x4mm
5x10x4mm
3x8x4mm
3x12mm
3x12mm
3x10mm
3x8x4mm
940510
BB 5x10x4
902312
SH M3x12
Bearing with BLUE
rubber covers
OIL
BEARING OIL
(HUDY #106230)
Bearing with BLUE
rubber covers
OIL
BEARING OIL
(HUDY #106230)
NOTE ORIENTATION
Dots must have same orientation on
each side (dots up or down).
NOTE
ORIENTATION
LOWESTLOWERMIDDLE
DIRTCARPET
#980320-T
TITAN PIN 3x20 (2)
2x
1x
1x
3x
1x
2x
#323019-G
FRONT MOTOR GEAR BOX
- LCG - GRAPHITE
Gear Diff
CARPET
CARPET
Gear Diff
CARPET
Ball Diff
DIRT
DIRT
Ball Diff
DIRT
