Xray XT2 User Manual

TOE-IN
ANTI-SQUAT
ROLL CENTER
TRACK-WIDTH
DIRTCARPET
ECCENTRIC BUSHINGS HAVE TWO DIFFERENT OFFSETS FROM
THE CENTER.
Middle position = 0.5° or 0.375mm from center.
Outer position = 1° or 0.75mm from center.
The XRAY rear alu lower suspension holders provide great range of adjustment for the rear suspension. Using different combinations of eccentric bushings, fine adjustment of rear anti-squat, rear toe-in, rear roll
center, and rear track-width can be obtained.
For more information about the influence of rear anti-squat, rear toe-in, rear roll center and rear track width on car handling, please refer to HUDY Set-up Book (#209100).
The tables describe the amounts of adjustment using the center and outside positions of the eccentric bushings.
The middle position eccentric bushings allow for finer adjustment increments.
Example:
The track-width is directly influenced by the size of
the wheels and tires used.
0(RR) - 0 (RF) = 2°
0(RR) - 0.5 (RF) = 2.5°
0(RR) - 1 (RF) = 3°
ANTI-SQUAT ROLL CENTER TRACK-WIDTH TOE-IN
RR RR RR RRRF RF
RF
RF(°) (mm) (mm) (°)
=2°
=3°
=1°
=3°
=2°
=4°
=1°
=2°
=0°
= 2°
= 2.5°
= 3°
=3°
=4°
=2°
=2°
=3°
=1°
=4°
=5°
=3°
=
+
1.5mm
= 0mm
=
-
1.5mm
=
+
0.75mm
= 0mm
=
-
0.75mm
15
RR
RF
THREAD LOCK
(all screws)
COMPOSITE ECCENTRIC BUSHINGS
INITIAL SETTING
1º 1º0.5º 0.5º0º
COMPOSITE ECCENTRIC BUSHINGS
INITIAL SETTING
1º 1º0.5º 0.5º0º
3. REAR SUSPENSION
903308
SFH M3x8
(TOE IN = 3 º / ANTI-SQUAT = 2º)
(TOE IN = 3 º / ANTI-SQUAT = 2º)
2mm
Arm Reamer 3.0mm
(HUDY #107643).
3.0mm
3.0mm
If the suspension arm DOES NOT move freely
use a HUDY Arm Reamer to size the holes of
the arms.
Check for free movement.
DETAIL
ARM
ARM
NOTE ORIENTATION
306219
SHIM 3x6x2
REAR SUSPENSION ARMS
#323112-M MEDIUM INCLUDED
#323112-H HARD OPTION
#323112-G GRAPHITE OPTION
REAR SOLID SUSPENSION ARMS
#323115-M MEDIUM OPTION
#323115-H HARD OPTION
#323115-G GRAPHITE OPTION
MEDIUM - For very-low & low traction.
HARD - For medium & high traction.
GRAPHITE - For high & very-high traction.
2x
4x
3x8mm
3x8mm
48mm
