2
Inner Power 1 Lock Connection
•
Lock Control Jumper:
Toselectthelocktype:whenconnectingaElectromechanicallock,setthejumperin1-2
position;whenconnectingaElectromagneticallock,setthejumperin2-3position.
•
Camera Code DIP:
Total4Cameracanbesupported
1 2
ON
SettotherstCamerawhenmultiCamerasaretobeinstalled;
SettotheCamerawhenthereisonlyoneCameratobeinstalled;
1 2
ON
SettothesecondCamerawhenmultiCamerasaretobeinstalled;
1 2
ON
SettothethirdCamerawhenmultiCamerasaretobeinstalled;
1 2
ON
SettothefourthCamerawhenmultiCamerasaretobeinstalled;
•
Main Connect Port:
Toconnectthebuslineandtheelectroniclocks.
• BUS:Connecttothebusline,nopolarity.
• PL:Externallockpowerinput,connecttothepowerpositive(power+).
• S1+,S2+:Lockpower(+)output,toconnect2locks.
• S-:Lockpower(-)output,connecttothepower(-)inputoflocks(onlywhenusingthecameratopowerthelocks,
ifusingtheexternalpowersupplyforthelocks,theS-willnotbeconnected).
Thestandardinnerpowerlockconnection,usetheCamerapowertosupplythelock,noneedforexternalpower
supply.TheUnlockModeinthemonitorneedtobeset:forPower-to-Unlocktypelock,UnlockModesetto0(in
Monitor,gotoMain-->Setup-->AdvancedSet-->Informationpage,thenpressandholdtheUnlockButtonfor2
secondstoopentheUnlockModesettingpage);forPower-Off-to-Unlocktypelock,UnlockModesetto1.
1 2
ON
1 2 3
to Monitor
-
+
BUS PL S1+ S2+ S- BUS PL S1+ S2+ S-
Jumper position in 1-2
Unlock Mode
0: power-on-to-open
1: power-off-to-open
The lock consumption must not
greater than 12V 500mA.
Electromechanical lock
1 2
ON
1 2 3
to Monitor
-
+
Jumper position in 2-3
The lock consumption must not
greater than 12V 300mA.
Electronmagnetical lock
CALL
UNLOCK
TALK/MON
IN-USE
MENU
Unlock Mode
0: power-on-to-open
1: power-off-to-open
CALL
UNLOCK
TALK/MON
IN-USE
MENU
Connection for Electromechanical lock Connection for Electromagnectical lock
