4
Mounting Without Rain Cover
Electronic Specications
Mounting With Rain Cover
160-165cm
1
2
1 2 3 4
160-165cm
1
2
1 2 3 4
LockPowersupply: 12Vdc,500mA(suppliedbysystem)
PowerConsumtion: 1Winstandby,12Winworking
Videosignal: 1V
p-p
75

ohmCCIR
NO,COMexchangecontact: Max.48Vdc1.5A
Unlockingtime: 1to9seconds,setbyMonitor
Workingtemperature: -5ºC+45ºC
