ERG160 Rower
5
ERG160 Parts List
Part No. Description Spec. QTY
1 Main frame 1
2 Slide rail 1
3 Front stabilizer 1
4 Rear stabilizer 1
5 Handlebar 1
6 Fixed plate for seat 2
7 Console bracket 1
8 Magnet bracket 1
9 Chain cover L 1
10 Chain cover R 1
11 Stop Brackets R 2
12L/R Pedal L/R 1/1
13 Pedal strap 2
14 Cross-head screw M5*15 1
15 Stop Brackets L 2
16 U-shaped plate 4
17 Belt 220J*14 1
18 Sensor bracket 1
19 Square end cap □40*80 1
20 Foot pat 1
21 Handlebar seat TPR 1
22 Belt pulley 1
23 Drawstring pulley 1
24 Volute spring cover ABS 1
25 Soundproof board A Ф142*Ф16*0.5 1
26 Soundproof board B Ф119*Ф16*0.5 1
27 Bearing 6003 1
28 Belt Wheel POM 1
29 Bearing 6000ZZ 5
30 Tension knob 1
31 Front Stabilizer end cap L PP 1
32 Front Stabilizer end cap R PP 1
33 Rear Stabilizer end cap PP 2
34 Limiter pad 72*20*T5.0 2
35 Round end cap 2
36 Foam grip 2
37 Meshbelt 1
38 Seat 1
