ERG220 Rower

5

ERG220 Assembly Pack Checklist

#44 OD20*ID8.5*1.5 2PCS

RE-6030

STEP-1

STEP-5

#81 M8*20 2PCS

STEP-3

#52 ID8.5 4PCS

#55 OD16*ID8.5*1.5 4PCS

#81 M8*20 4PCS

#55 OD16*ID8.5*1.5 4PCS

#52 ID8.5 4PCS

#81 M8*20 4PCS

#65 ∅12 1PC

STEP-6

#64 ∅18*∅13*26 2PCS

#50 M12*160 4pcs

#34 1PC

#11 1PC

#15 1PC

#59 2PCS

#62 2PCS

# 98 S13-14-19 1PC

TOOL

# 97 S6 2PCS

#55 OD16*ID8.5*1.5 2PCS

STEP-4

#52 ID8.5 2PCS

#81 M8*20 2PCS

STEP-2

#97

#97

#65 Ball Head Pin

#50 Long Screw

#64

Spacer

#98

#46 Axis, #81 Screws, #44 Washers
