XtraVac CM430 Chamber Machine Operation and Parts Manual
XtraVac Packaging Machines 419 E. 11th Ave. North Kansas City, MO 64116 USA
CM430 Chamber Machine
+ +1 800 728 2999 Sales@XtraVac.com
16
XtraVac430
No Description Part Number No Description Part Number
2 FOOT PAD XVT466707 20 SEALING PAD XVT456318
3 VACUUM CHAMBER XVT467819 21 O-RING XVT457473
4 GLAND XVT463016 22 PE PAD LARGE HOLE XVT462166
5 UPPER LID XVT457469 23 FIXING NUT XVT462167
6 HEX SCREW XVT467838 24 RUBBER PAD XVT466522
6--1 HEX SCREW XVT467821 25 SCREW XVT467839
7 LONG HINGE XVT467822 26 CONNECTOR XVT468004
7--1 SHORT HINGE XVT467823 27 ROUND HEAD SCREW XVT465889
7--2
TOUCH PLATE OF LIMIT SWTICH
XVT75533 28 PE PAD SMALL HOLE XVT462443
8 PIN XVT467826 29 RUBBER PAD XVT466714
9 E-CIRCLIP XVT460651 30 AIR BAG SUPPORT XVT467842
10 Washer XVT460654 31 ROUND HEAD SCREW XVT468225
11 Hex nut XVT465349 32 U SHAPE BOARD XVT458061
11--1 HEX SCREW XVT467829 U SHAPE BOARD XVT458062
12 SPRING WASHER XVT465349 33 FLAT WASHER XVT70835
13 FLAT WASHER XVT460651 34 ROUND HEAD SCREW XVT458060
13-1 Spring washer XVT72931 35 AIR BAG SUPPORT XVT456309
14 SPRING WASHER XVT70835 36 AIR BAG COVER XVT467845
15 ROUND HEAD SCREW XVT458060 37 ROUND HEAD SCREW XVT467846
15-1 ROUND HEAD SCREW XVT464574 38 PRESS WIRE PLATE XVT464564
16 RUBBER GASKET XVT468898 39 ROUND HEAD SCREW XVT468005
17 PE PAD Lid XVT467834 40 HEATING UNIT XVT458059
18 SEALING SUPPORT XVT467835 40-1 HEAT RESISTANCE TAPE XVT456315
19 INNER HEX SCREW XVT75514 41 HEATING WIRE XVT456316
19-1 T-NUT XVT467832 42 HEAT RESISTANCE TAPE XVT456315
19-2 SEAL XVT467877 43 HEX NUT XVT70982
