Xtreamer Prodigy User Manual

7
Video & Audio Output Connections
ㆍHDMI cable connection
Connections
ㆍComposite cable connection
Connect HDMI cable to HDMI terminal at the back of product. Connect the remaining cable
terminal to HDMI terminal at the back of a digital TV. Make sure to carefully distinguish
between input and output terminals.
Connect yellow cable for video signal to the terminal located at the back of side of TV. Then,
select external input of TV. Connect the remaining red and white terminal cables to the left/ right
and audio output terminal at the back of the device. Then, connect red and white cables to the
left/ right terminal of DTV input or component audio input located at the back of a digital TV.

Xtreamer Prodigy Specifications

General

HDD size	3.5 \
HDD interface	Serial ATA
Storage media type	HDD
Built-in storage media	No
Card reader integrated	Yes
Total storage capacity	0 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC
Maximum storage capacity	3 TB
Number of HDDs installed	0
Connectivity technology	Wired
AV output	1
HDMI version	1.4
USB 2.0 ports quantity	2
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio decoders	Dolby Digital 5.1, Dolby TrueHD
Audio output channels	7.1 channels
Internal memory	512 MB
Internal memory type	DDR3
TV tuner type	DVB-T
Processor frequency	750 MHz
Cables included	HDMI, USB
Number of products included	1 pc(s)
Product color	Silver
Supported radio bands	FM
Audio formats supported	AAC, HE-AAC, LPCM, MP2, MP3, OGG, PCM, WAV, WMA
Image formats supported	BMP, GIF, JPG, PNG, TIF
Video formats supported	ASF, AVI, DAT, FLV, ISO, M4V, MKV, MOV, MP4, MPG, TP, TRP, TS, WMV
Video compression formats	DivX, MPEG1, MPEG2, MPEG4, WMV, Xvid
Subtitle formats supported	smi, srt, ssa, sub, sub+idx
Analog signal format system	NTSC, PAL
AC input voltage	100 - 240 V

Weight and Dimensions

Weight	- g
