SPECIFICATIONS
Tuning Bandwidth
Working Range
Audio Frequency Response
Dynamic Range
Battery Life
RF Sensitivity
Total Harmonic distortion
RF Output Power
Operating Temperature Range
Channel Count
Maximum Level
Sample Rate
2400 – 2483.5MHz
>70 feet Line-0-site outdoors. Actual range depends on RF signal
absorption, reflection and interference.
20Hz – 20KHz(-3dB). Dependent on microphone type or Input signal.
>103dB
Up to 5 hours (3.7V Rechargeable Li-lon, 650mA)
-85dBm
0.2%
10 mW E.I.R.P. max
-18ȭ to 57ȭ. Battery characteristics may limit this range.
up to 4 Channels
Input: 5.6Vp-p Output: 5.6Vp-p
24bit/48K Hz uncompressed digital transmission
13
