ITEM NUMBER PART
NUMBER DESCRIPTION REQUIRED NUMBER
1 Motor - Order by Description 1 Consult Factory
2 Impeller 1 Consult Factory
3 Pump Head 1 DP0208
4 Case with Wear Ring 1 DP1603
5 Wearing Ring 1 DP0482
8 Impeller Capscrew 1 DJ0213
9 Impeller Washer 1 DJ0267
10 Capscrews 8 DJ0066
16 Water Slinger 1 DP0848
Seal Kit including Mechanical
6-7
Seal, Head Gasket
1 180014
Case to Receiver Gasket 1 DG0060
616PF PUMP USED ON SCC
1
10
16
3
10
6
7
9
8
4
52
Order Replacement Parts by Description and Part No.
Specify Serial No. shown on nameplate.
11
