Page #364 background image
it en fr de es pt nl pl el tr ru ar
364
18.
INST-QSMART1APPL7B_G_20_B-SC
P MIN
0V
A IN (0/4-20mA)
+12V
D IN PROG
+12V COM
+12V COM
+12V COM
+12V COM
+12V COM
P MIN/G MIN
P MAX/G MAX
P2/G2
P1/G1
S MAX
S 2
S 1
S MIN
S COM
Q-SMART
c01 = 1
P 1
bS1
c03 = 4
t10 = 0 sec
t11 = 0 sec
r34 = 1 (NC)
r36 = 1 (NC)
t36 = 0 sec
r37 = 1 (NC)
t37 = 0 sec
c53 = 1
t53 = 0 sec
P MIN
G MIN
P 1
