Model
LF-852D REWORK STATION
Power Voltage 100-120Vac 60Hz 220-240Vac 50Hz
Power Consumption (Max) 600W
Pump Diaphragm 115Vor120V 230V or 240V
Air Flow 1.5L-40L /Min
Temperature range 212℉-896℉ 100℃-480℃
Dimensions 283(W)*120(H)*190(D) mm
Fuse (Fast type) 5A
SPECIFICATIONS
BRIEF INTRODUCTION OF PANEL FUNCTIONS:
Front panel
○
1 Main power switch
○
2 Hot air pencil inlet
○
3 “▲”: Temperature increasing (UP)
○
4 “▼”: Temperature decreasing(Down)
○
5 Temp Display
○
6 “SET”: Temperature setting display
○
7 “▲”: Hot air blow (UP)
○
8 Air blow display
○
9 “▼”: Hot air blow (DOWN)
OPERATING PRECAUTIONS
1. Make sure both heater and nozzle are cool before attaching the nozzle.
4
