Components - Fittings
Please check you have all the panels listed below
Note:The quantitie below are the correcet amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Tools required
Ruler - Use this ruler to help correctly identify the screws
0
5
10 15 20 25 30 35 40
45
50
55
60 65 70
75
80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
The screws length is measured from the head to the point (35mm screw shown).
Phillips screwdriver
(medium & large)
6*12mm Bolt x16
Cam Bolt x36
Cam Lock x36
4*25mm Bolt x6
Drawer Slide 14" x2
Shelf Support Pin x12
Allen Key x1
Locking Caster x2
Handle x3
3.0*12mm Screw x38
Caster x2
Flat Washer x4
Lock Washer x4
4*35mm Screw x16
Vertical nut x4
Door Catch x2
3.0*16mm Screw x4
Door Hinge x4
Ø6*30mm Dowel x42
A
B
C D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
6*60mm Bolt x4 6*45mm Bolt x4
Hole to Stick x4
Support Hinges x1
4*15mm Screw x4
Z
Butt Hinge x3
4*15mm Screw x18
To Next Page
