Yale CPA Series User Manual

15
Yale-part. No.
No. Description Qty. CPA 20-8 CPA 30-6 CPA 40-4 CPA 50-3 CPA 60-3
1-11 Suspension unit assy. 1 0609449 0609449 0609449 0609449 0609449
1 Body half, motor side 1 0608972 0608972 0608972 0608972 0608972
2 Body half, gearbox side 1 0608974 0608974 0608974 0608974 0608974
3 Chain guide 1 0608976 0608976 0608976 0608976 0608976
4 Chain stripper 1 0608978 0608978 0608978 0608978 0608978
5 Load chain sheave 1 0609374 0609374 0609374 0609374 0609374
6 Roll pin 2 9134001 9134001 9134001 9134001 9134001
7 Pin 2 9124169 9124169 9124169 9124169 9124169
8 Pin 2 9124111 9124111 9124111 9124111 9124111
9 Bearing 1 9151106 9151106 9151106 9151106 9151106
10 Screw 1 9102253 9102253 9102253 9102253 9102253
11 Screw 2 9102254 9102254 9102254 9102254 9102254
12 Air motor 1 0850003 0850003 0850003 0850003 0850003
13 Planetary gearbox 1 0609678 0608814 0609678 0608814 0608814
14 Screw 8 9101660 9101660 9101660 9101660 9101660
15 Shaft 2 0609388 0609388 0609388 0609388 0609388
16 Locking plate 1 0609448 0609448 0609448 0609448 0609448
17 Screw 2 9102150 9102150 9102150 9102150 9102150
18 Plug 2 9110007 9110007 9110007 9110007 9110007
20 Plug 1 9192003 9192003 9192003 9192003 9192003
21 Plug 1 9192002 9192002 9192002 9192002 9192002
22-23 Suspension hook assy. 1 0609393 0609393 0609517 0609517
23 Safety latch kit 1 0408671 0408671 0408671 0408671
25 Nameplate 1 0800058 0800058 0800058 0800058 0800058
26 Nail 2 9128004 9128004 9128004 9128004 9128004
27 Capacity plate 1 0600002 0609696 0600001 0609511 0600212
28 Nameplate 2 0609692 0609692 0609692 0609692 0609692
29 Anchor pin 1 --- --- 0608855 0608855 0608855
