Yale CPV Series User Manual

Yale Electric Chain Hoist - CPV/F
®
7
www.yaleproducts.com
Motor data CPV 460V - 3Ph - 60Hz
Model PnED Kind of I Efficiency Number of Protection Motor Fuse
connection
n
of starts degree class (slow)
kW 1/min %Amotor c/h A
CPV 2-8
0.44 3480 50 Y 0.8 85% 300 IP55 S3 6
CPV 5-4
CPV 5-8
0.9 3480 50 Y 1.6 86% 300 IP55 S3 10
CPV 10-4
CPV 10-8
1.8 3450 50 Y 3.2 86% 300 IP55 S3 16
CPV 20-4
Motor data CPV/F 400V - 3Ph - 50Hz
Model PnED Kind of I Efficiency Number of Protection Motor Fuse
connection
n
of starts degree class (slow)
kW 1/min %Amotor c/h A
CPV/F 2-8
0.09/0.37 640/2850 17/33 Y / Y 0.55/1.0 59%/78% 200/100 IP55 S3 6
CPV/F 5-4
CPV/F 5-8
0.18/0.75 620/2800 17/33 Y / Y 0.95/2.0 65%/82% 200/100 IP55 S3 10
CPV/F 10-4
CPV/F 10-8
0.37/1.5 640/2850 17/33 Y / Y 1.60/3.3 64%/89% 200/100 IP55 S3 16
CPV/F 20-4
Motor data CPV/F 460V - 3Ph - 50Hz
Model PnED Kind of I Efficiency Number of Protection Motor Fuse
connection
n
of starts degree class (slow)
kW 1/min %Amotor c/h A
CPV/F 2-8
0.11/0.44 770/3420 17/33 Y / Y 0.55/1.0 59%/78% 200/100 IP55 S3 6
CPV/F 5-4
CPV/F 5-8
0.25/0.90 740/3360 17/33 Y / Y 0.95/2.0 65%/82% 200/100 IP55 S3 10
CPV/F 10-4
CPV/F 10-8
0.44/1.8 780/3380 17/33 Y / Y 1.60/3.3 64%/89% 200/100 IP55 S3 16
CPV/F 20-4
Motor data CPV 230/400V - 3Ph - 50Hz
Model PnED Kind of I Efficiency Number of Protection Motor Fuse
connection
n
of starts degree class (slow)
kW 1/min %Amotor c/h A
CPV 2-8
0.37 2890 50 Y / delta 1.38/0.8 84% 300 IP55 S3 6
CPV 5-4
CPV 5-8
0.75 2890 50 Y / delta 2.8/1.6 85% 300 IP55 S3 10
CPV 10-4
CPV 10-8
1.5 2860 50 Y / delta 5.5/3.2 85% 300 IP55 S3 16
CPV 20-4
Y
ale
CPV/F
®

Yale CPV Series Specifications

General

Load Chain	Grade 80 alloy steel
Finish	Painted or powder-coated
Type	Chain Hoist
Standard Lift	3m
Housing Material	Steel
Lift Height	3 m (Standard). Higher lifts available.
Operation Type	Manual
Construction	Steel
