Yale HSA6080 User Manual

Specification
Conforms to:
EN 300 220-1 / V2.1.1 (2006-04)
EN 301 489 -1, / V1.6.1 (2004-12)
EN 301 489-3, / V 1.4.1 (2002-08)
Environmental conditions:
-10°C to 40°C, relative humidity
70% non-condensing
Radio: Microcontroller controlled
433.92MHz AM transmitter.
Battery: 3V, CR2032 lithium
coin cell. 3 years typical domestic
service life
Programming &
testing
Program your Keypad before
installation and test afterwards.
Please see your current system
instruction book.
Location
Locate the keypad taking into account
the following points:
• Accessible when entering
• Not visible from outside
• Protected by another device
• Chest height for ease of use
• Not outdoors
Mounting
1 Open cradle to reveal mounting slots
2 Using the slots as a template, drill
holes in the surface and insert wall
plugs if fixing into plaster or brick.
Screw the cradle to the wall. 3 Slide
keypad into cradle.
ale
Y
R
1
2
3
6
5
4
7
8
9
0
A
B
Disarm
Home
Arm
Arm
LED
Battery
saver tab
Yale UK
School Street, Willenhall
W
est Midlands WV13 3PW
Tel +44 (0)1902 364647
Fax +44 (0)1902 364692
E-mail info@yale.co.uk
www.yale.co.uk
E1 12/06
