Yale MCW040-E

Table 7. Battery Specifications for MSW020/025-E
Lift Truck Specifications Battery Specifications
Model Volt
Battery Compartment Width
(Max)
mm (in.)
"X"
Length
(Max)
mm (in.)
"Y"
Height
(Max)
mm (in.)
Weight Rating
(Max)
kwh
(amp hr)
Width
mm (in.)
Length
mm (in.)
(Min)
kg (lbs)
(Max)
kg (lbs)
Maintenance
Free Battery
Pack
a
24 720 (28.3)
205 (8.0)/
230 (9.0)
693 (27.3) 190 (7.5) 670 (26.4) 262 (578) 163 (359) 4.4 (195)
MSW020-E
Flooded
Cell
Battery Pack
24 720 (28.3) 205 (8.0) 716 (28.1) 200 (7.9) 733 (28.8) 217 (478) 140 (310) 4.0 (158)
MSW025-E 24 720 (28.3) 230 (9.0) 642 (25.3) 162 (6.4) 592 (23.3) 185 (410) 287 (633) 3.5 (150)
MSW025-E 24 720 (28.3) 230 (9.0) 642 (25.3) 162 (6.4) 592 (23.3) 192 (425) 297 (655) 3.9 (170)
MSW025-E 24 720 (28.3) 230 (9.0) 642 (25.3) 162 (6.4) 592 (23.3) 213 (470) 329 (725) 4.6 (200)
MSW025-E 24 720 (28.3) 230 (9.0) 652 (25.7) 223 (8.8) 592 (23.3) 244 (540) 378 (833) 5.2 (225)
MSW025-E 24 720 (28.3) 230 (9.0) 652 (25.7) 223 (8.8) 592 (23.3) 258 (570) 400 (882) 6.0 (255)
NOTE: Used for both MSW020-E and MSW025-E.
Steel tray with cover required for all batteries.
Battery connector type is 175 Amp RED (Gray is optional).
Cable lead position "B."
20" Cable length.
Maximum cable gauge of 1/0.
Maintenance
84
