Yale RH00436G - Page 6

List of Materials
4
(3) Wire Nuts
(1) Suction Cup
(4) 6 x 1-1/2”
(wood screws)
(2) M4 x 8
(top support
frame screws)
(1) M4 x 12
(safety screw)
(12) M3 x 6
(duct cover screws)
1 - Hardware package
2 - Thick trim pieces
2 - Thin trim pieces
1 - Top support frame
1 - Bottom support frame
2 - Top duct covers
2 - Bottom duct covers
1 - Hood body w/ blower (pre-installed)
1 - Canopy, glass or stainless
2 - Aluminum mesh filters
2 - 50W GU-10 halogen lights
1 - 6” round damper (pre-installed)
MODELS: RH00436G, RH00436S
PARTS SUPPLIED
HARDWARE PACKAGE CONTENTS
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Duct cover extension accessory
- Recirculating kit accessory
(4) 3/16 x 8
(canopy screws)
A
B
Front of Hood
C
L
/
Cut-Out Shaded Area
1 - Paper ceiling
template
(4) ø12 OD / ø5 ID
Washers
