ZAPI™ PC Interface 2200 YRM 1067
Now that the parameters have downloaded, you should
see a screen as indicated in Figure 26.
Figure 26. Drive Mode
Please note that the current drive mode the lift truck
was in will be displayed. (There are three modes that
cannot be adjusted.) In order to make any changes
to the parameters, you must turn on Mode 4, which is
covered in Set Options, in this section.
Adjustments can be made by first highlighting the pa-
rameter to be modified and then using the scroll bar on
the right side of the screen to adjust it.
Youwillalsonoticethattherearesixtabsalongthetop
to choose from:
1. Parameter Change - Allows the performance of the
truck to be adjusted.
2. Set Options - Allows the technician to turn on or
off mode 4 for personalized performance settings.
See Set Options.
3. Set Model -NotUsed.
4. Adjustment -NotUsed.
5. Special Adjust - Not Used.
6. Hardware settings -NotUsed.
48
