2200 YRM 1067 ZAPI™ PC Interface
Highlight Drive Modes and then click on the scroll bar
to the right and select OFF. See Figure 31.
Figure 31. Turn Off Drive Modes
Do the following steps once this has been done:
1. Press the Store button to save the change into the
controller.
2. PresstheClosebuttontogotothemainscreenof
the ZAPI™ PC software.
3. Press the Stop button to disconnect the communi-
cation between the PC and the controller.
4. TurnthekeyswitchonthelifttrucktoOFF; then do
the reconnect procedure.
5. Now the parameters in the Function Menu can be
adjusted to a custom configuration (Mode 4).
53
