14
SR140P25DAL SR140P38DAL SR140P50DAL SR125D13DAL
<881113> <881114> <881115> <881125>
1 (854564) Drum lift assembly
－
1-1 832981 Drum base assembly 1
1-2 832983 Lift assembly 1
1-3 611197 Bolt 4
1-4 631918 Spring washer 4
1-5 686820 Slide pack 2
1-6 686327 Bolt 30
1-7 631495 Washer 30
1-8 717094 Slide base 1
1-9 717093 Slide base 1
1-10 716325 Plate 1
1-11 611145 Bolt 12
1-12 631916 Spring washer 22
1-13 611153 Bolt 6
1-14 716326 Spacer 3
1-15 611172 Bolt 8
1-16 631917 Spring washer 8
1-17 832982 Pump base assembly 1
1-18 716327 Cover 1
1-19 602992 Screw 8
1-20 686326 Bushing 2
1-21 686324 Throttle 2
1-22 686308 Air cylinder 1
1-23 686309 Trunnion holder 1
1-24 686310 Knuckle joint 1
1-25 686311 Clevis 1
1-26 683821 Elbow fitting 1
1-27 686329 Pannel union 1
1-28 804822 Operation pannel assembly 1
1-30 631013 Plain washer 14
1-31 631014 Plain washer 4
1-32 619151 Bolt 4
1-33 602702 Screw 4
1-34 619075 Bolt 16
1-35 631417 Spring washer 16
2 854560 854561 854562 854664 Pump assembly 1
4 (804823) Inductor plate assembly
－
4-1 770218 Packing 1
4-2 770217 Packing 1
4-3 611103 Bolt 12
4-4 631418 Spring washer 12
4-5 710931 Plate 6
4-6 716332 Follow plate 1
4-7 772150 Gasket 1
4-8 631916 Spring washer 4
4-9 611149 Bolt 4
4-10 716333 Filter 1
4-11 686331 Screw 4
4-12 701764 Handle 1
4-13 715802 Valve rod 1
4-14 715803 Socket 1
4-15 682802 Fitting 1
4-16 634061 Tee 1
4-17 634802 Nipple 1
4-18 800977 Check valve 1
4-19 685680 Relief valve 1
4-20 634595 Bushing 1
4-21 681170 Silencer 1
6 716322 Angle 4
7 611145 Bolt 8
8 631916 Spring washer 8
9 683820 Elbow fitting 1
※
Stopper is included with 686820 slide pack.
No. Description Q'ty
Part No.
■Parts List
800977
Check valve
No. Part No. Description Q'ty
4-18-1 704407 Valve body 1
4-18-2 630316 Ball 1
4-18-3 704408 Tapered spring 1
4-18-4 706513 Washer 1
4-18-5 704409 Union 1
To Next Page
