YAMADA NDP-5 series User Manual

10
1
11
1.
..
.3
3 3
3 NDP
NDPNDP
NDP-
--
-10
1010
10/12
/12/12
/12 series
series series
series
A: Air Valve F : Pump Base
B: Reset Button G: Discharge Port
C: Out Manifold H: Intake Port
D: Out Chamber I: Lift Point
E: In Manifold J: Ground Connection Point
NDP-10-BPC, NDP-10-BPN
NDP-10-BPT, NDP-10-BPS
NDP-10-BPH, NDP-10-BPE
•Polypropylene type
Type BPC BPN BPT BPH BPS BPE
Switching Portion PPS
Fluid contact Portion ADC12
Diaphragm CR NBR PTFE TPEE TPO EPDM
Ball/O Ring CR/NBR NBR PTFE PTFE EPDM EPDM
Valve Seat CR NBR PPG PPG PPG PPG
Center Disk PPG (SUS304)
█ List of accessories
List of accessoriesList of accessories
List of accessories
• Operation Manual ·············· 1
• Maintenance Manual ·········· 1
• Air valve··························· 1
• Accessory tool ···················· 1
