Questions and Answers:

J
James GreenAug 16, 2025
Why my YAMADA TOTE IP140S3-TE Water Pump does not run?
- B
  Benjamin DodsonAug 16, 2025
  If your YAMADA Water Pump isn't running, there are several potential causes: * **Air supply issues:** Ensure the compressor is on, and both the air valve and air regulator are open to supply air. * **Low supply pressure:** The air pressure needs to be at least 30 psi. Adjust the pressure accordingly. * **Closed discharge flow valve:** Make sure the ink delivery valve is open. * **Icing in exhaust port:** Install an air line coalescing filter to remove moisture and prevent icing.
K
kingscottAug 19, 2025
What to do if there is air leakage from the air motor of my YAMADA Water Pump?
- N
  Natalie BlakeAug 19, 2025
  If you notice air leakage from the air motor of your YAMADA Water Pump, it could be due to loosened screws connecting parts or damage to the O-ring, packing, or a similar component. Try tightening the screws at the affected area. If that doesn't solve the problem, replace the damaged parts.
L
Linda BrowningAug 22, 2025
What to do if my YAMADA TOTE IP140S3-TE Water Pump does not deliver ink?
- M
  Maria GonzalesAug 22, 2025
  If your YAMADA Water Pump does not deliver ink, it could be due to several reasons related to the plunger and valve operation. If the plunger operates faster during the moving-up process, the seat of the piston valve may be malfunctioning (worn out or contaminated), or the packing may be damaged. If the plunger operates faster during the moving-down process, the seat of the foot valve may be malfunctioning, the packing may be damaged, or the shovel rod may be bent. In either case, replace the malfunctioning part or remove any foreign substances. Also, ensure that the screw fixing the air motor and the plunger of the lower pump is tightened.
W
walshleslieAug 25, 2025
What to do if my YAMADA TOTE IP140S3-TE Water Pump does not stop?
- J
  Joanne JenkinsAug 26, 2025
  If your YAMADA Water Pump doesn't stop, check for ink leakage from the ink delivery pipe connection. If you find a leak, tighten the screw at the connection or replace the damaged part. Also check for Ink leakage from the parts-connecting section of the suction pump assembly.
A
Anthony FloresAug 28, 2025
Why is there air entrained in ink in my YAMADA Water Pump?
- R
  Ronald RobinsonAug 28, 2025
  If you observe air being entrained in the ink of your YAMADA Water Pump, it's likely due to loosened screws connecting parts of the lower pump, or damage to the O-ring, back-up ring, or gasket. Address this by tightening the screws at the affected section or replacing any damaged components.
U
ujonesAug 31, 2025
What causes ink leakage from the suction pump in my YAMADA Water Pump?
- A
  Ashley OwensAug 31, 2025
  If you notice ink leakage from the suction pump of your YAMADA Water Pump, it's likely that the screws connecting parts are loose, or the O-ring, back-up ring, packing, or similar part is damaged. You should tighten the screws at the malfunctioning section or replace the damaged part.
B
Benjamin KingSep 3, 2025
Why is the oil container of my YAMADA Water Pump swelling?
- P
  phamsavannahSep 3, 2025
  If you find that the oil container of your YAMADA Water Pump is swelling or dissolving, it could be due to two reasons. First, make sure you are using an overflow catch bottle when operating the pump. Second, the solvent may be attacking the acrylic resin. In this case, switch to using spindle oil with an ISO viscosity grade of 10.
S
Sarah HawkinsSep 6, 2025
What to do if my YAMADA TOTE IP140S3-TE Water Pump does not prime ink during start up?
- D
  Dr. Laura BuckleySep 6, 2025
  If your YAMADA Water Pump does not prime ink during start up, it might be because the supply air pressure is too high. To resolve this, run the pump at a slower rate, about 8-10 cycles per minute, until ink discharges from the bleeder valve.
P
Patrick SmithSep 9, 2025
Why does the amount of liquid increase rapidly in the oil container of my YAMADA Water Pump?
- K
  kingallenSep 9, 2025
  If you observe a rapid increase in the amount of liquid in the oil container of your YAMADA Water Pump, it's likely that the gland seal is worn out or damaged. Replace the gland seal with a new one to resolve this issue.
D
Daniel HallSep 12, 2025
Why is there air leakage from the silencer during stop of my YAMADA TOTE IP140S3-TE Water Pump?
- J
  james48Sep 12, 2025
  If you notice air leakage from the silencer of your YAMADA Water Pump during stop, it could be due to a foreign substance caught between the block inside the switching valve (804355 or 804358) and the sliding section of the switching valve seat (705688), the seat being worn out, or the gasket (772331) being damaged. You should replace the damaged part or remove the foreign substance.
