E
4-19
EMU01308
200A, L200A
NOTE:
If any water is in the fuel, the float 7 will
rise. If so, remove the cup and drain the
water.
1) Loosen and remove the locking tab bolt
and tab 1. Slightly loosen the filter cup
ring nut 2.
2) Remove the filter cup 3, catching any
spilled fuel in a rag.
3) Remove the filter element 4, and wash
it in solvent.
Allow it to dry. Inspect the filter element
and O-ring 5 to make sure they are in
good condition. Replace them if neces-
sary.
4) Reinstall the filter element. Make sure
the O-ring is in position in the cup.
Insert the cup and O-ring into the filter
housing 6. Screw the ring nut onto the
filter housing until the ring is lightly
seated.
5) Tighten the ring nut approximately an
additional 1/4 turn until ring nut is tight.
Align one of the four larger ring nut tabs
into the slot of the locking tab. Install
the locking tab bolt and tighten.
6) Run the engine and check the filter and
lines for leaks.
001332
q
001331
w
e
r
t
y
u
200A, L200A
60H-9-E1-4 3/1/02 9:39 PM Page 20
