Why doesn't my Yamaha 15FMH Outboard Motor boat speed gauge show?
If the boat speed and/or coolant pressure gauge isn't showing, it means the optional sensor hasn't been installed. Install the optional sensor to fix this.
What to do if the Yamaha 15FMH Outboard Motor gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha 15FMH illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha Outboard Motor tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha 15FMH Outboard Motor fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
Why does my Yamaha Outboard Motor fuel management gauge show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting is probably wrong. Fill the tank with fuel, and then set the correct fuel tank capacity.
What to do if my Yamaha 15FMH speedometer shows the incorrect fuel level?
If the speedometer shows an incorrect fuel level, the fuel sensor selection is likely wrong. You should set up the fuel sensor to the correct resistance.
What does it mean when my Yamaha 15FMH gauge shows “----”?
If the gauge shows “----”, it indicates that the digital signal is not being received. Make sure the couplers are securely connected and replace any damaged bus wires or hubs.
Why Yamaha Outboard Motor boat speed and/or coolant pressure gauge does not show?
If the boat speed and/or coolant pressure gauge does not show, it is likely that the optional sensor has not been installed. Install the optional sensor.
What causes Yamaha 15FMH gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
Instructions on correctly positioning and securing the outboard motor on the boat transom.
Table correlating engine RPM ranges with Wide-Open-Throttle operation for propeller selection.
Description, compatibility, and features of the 703 side mount mechanical remote control.
Description of the Digital Electronic Control (DEC) binnacle mount remote control unit.
Description of the 6x4 multi-function tiller handle and its electrical functions.
Functions, applications, kit contents, and dimensions of the fuel management gauge.
Representative wiring diagram samples and wire color code explanation.
List of engine models compatible with the digital network gauges.
Details on the immobilizer unit and its acceptable engine models.
Table of common gauge issues, causes, measures, and notes.
Wiring diagrams for single station 6Y9 gauge applications.
General| Engine Type | 2-stroke |
|---|---|
| Displacement | 246 cc |
| Prop Shaft Horsepower | 15 hp |
| Fuel Induction System | Carburetor |
| Ignition System | CDI |
| Starting System | Manual |
| Lubrication System | Premix |
| Gear Ratio | 2.08:1 |
| Maximum Output | 15 hp |
| Gear Shift | F-N-R |
| Shaft Length | 15 inches |
| Steering | Tiller |
| Trim System | Manual |
| Bore x Stroke | 56 x 50 mm |
| Full Throttle RPM Range | 4500-5500 rpm |
| Dry Weight | 36.0 kg (79 lbs) |
| Fuel Tank Capacity | 24 L (6.3 US gal) |
