Yamaha 150AET - Flywheel Magnet Assembly; Removing and Installing Flywheel Magnet Assembly

5-1
POWR
E
FLYWHEEL MAGNET ASSEMBLY
FLYWHEEL MAGNET ASSEMBLY 5
REMOVING/INSTALLING THE FLYWHEEL MAGNET ASSEMBLY 5
Å S150F, LS150F, S175D, S200F, LS200F/S150TR, L150TR, S175TR, S200TR, L200TR
ı Oil injection and 225DET models
Ç Pre-mix except for 225DET models
Order Job/Part Q’ty Remarks
1 Flywheel magnet assembly cover 1
2 Flywheel magnet assembly nut 1
3 Washer 1
4 Flywheel magnet assembly 1
5 Woodruff key 1
For installation, reverse the removal
procedure.
5010
