4-5
6X4 MULTI-FUNCTION TILLER HANDLE
HANDLE FITTING KIT CONTENTS
F115B
KIT P/N: 6X4-42102-C0
Part name Part No. Q’ty Remarks
STR friction assy 67G-42508-10 1
Stud bolt 90116-10063 2
Locknut 90185-10027 2 M10
Bracket 6EK-42121-00 1
Shift cable 6EK-48321-00 1 820 mm (33.5 in)
Clip 90468-10005 2
Cable clamp 63D-48538-00 2
Throttle cable 6EK-26301-00 1 710 mm (29.1 in)
Clamp 90464-09M42 1
10-pin main harness 6X4-82586-10 1 950 mm (37.4 in)
Clamp 90465-13M24 1
Troll RPM switch assy 6X4-81860-00 1
To Next Page
