MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
CVP-409/407/405/403/401 Data List
68
MIDI CHANNEL MESSAGE (2)
NRPN
[MIDI] [Song Creator]
● : Transmitted via panel operations and keyboard/controller performances.
NRPN MSB: 14H-1FH (for drums) message is accepted as long as the channel is set with a drum voice.
Data Entry LSB: Ignored.
NRPN (Vocal Harmony)
[MIDI] [Song Creator]
● : Transmitted via panel operations and keyboard/controller performances.
Message is sent to the Song Channel part set in MicSetting → Vocoder Control → Song Channel.
Data Entry LSB: Ignored.
NRPN Data Entry Parameter Data Range Voice MIDI Reception MIDI Transmission PLAY REC
MSB LSB MSB LSB Regular/Drum/
Natural/Organ
Voice
Mic/Vocal
Harmony
Song Right1/
Right2/
Left
Keyboard Style Extra Right1/
Right2/
Left
Style Song Upper
Lower
PLAY REW
From
panel
(Right1/
Right2/
Left)
01H 08H mmH -- Vibrato Rate mm: 00H-40H-7FH (-64...0...+63) O O
(Harmony
Channel/Melody
Channel)
OO X OO ● OO XOO O
01H 09H mmH -- Vibrato Depth mm: 00H-40H-7FH (-64...0...+63) O O
(Harmony
Channel/Melody
Channel)
OO X OO ● OO XOO O
01H 0AH mmH -- Vibrato Delay mm: 00H-40H-7FH (-64...0...+63) O O
(Harmony
Channel/Melody
Channel)
OO X OO ● OO XOO O
01H 20H mmH -- Low Pass Filter Cutoff
Frequency
mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
01H 21H mmH -- Low Pass Filter Resonance mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
01H 30H mmH -- EQ Bass Gain mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
01H 31H mmH -- EQ Treble Gain mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
01H 34H mmH -- EQ Bass Frequency mm: 04H-28H (32...2.0k[Hz]) O X O X X X X X X O X O O X
01H 35H mmH -- EQ Treble Frequency mm: 1CH-3AH (500...16.0k[Hz]) O X O X X X X X X O X O O X
01H 63H mmH -- EG Attack Time mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
01H 64H mmH -- EG Decay Time mm: 00H-40H-7FH (-64...0...+63) O X O O X O O ● OO XOO O
01H 66H mmH -- EG Release mm: 00H-40H-7FH (-64...0...+63) O X O X X O X X X O X O O X
14H rrH mmH -- Drum Low Pass Filter
Cutoff Frequency
rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
(
Drum only )
XOXXXXXOOXOXX
15H rrH mmH -- Drum Low Pass Filter
Resonance
rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
( Drum only )
XOXXXXXOOXOXX
16H rrH mmH -- Drum EG Attack Rate rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
(
Drum only )
XOXXXXXOOXOXX
17H rrH mmH -- Drum EG Decay Rate rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
(
Drum only )
XOXXXXXOOXOXX
18H rrH mmH -- Drum Pitch Coarse rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
( Drum only )
XOXXXXXOOXOXX
19H rrH mmH -- Drum Pitch Fine rr: drum instrument note number
mm: 00H-40H-7FH (-64...0...+63)
O
( Drum only )
XOXXXXXOOXOXX
1AH rrH mmH -- Drum Level rr: drum instrument note number
mm: 00H-7FH (0...127)
O
( Drum only )
XOXXXXXOOXOXX
1CH rrH mmH -- Drum Pan rr: drum instrument note number
mm: 00H, 01H-40H-7FH
(RND, L63...C...R63)
O
( Drum only )
XOXXXXXOOXOXX
1DH rrH mmH -- Drum Reverb Send Level rr: drum instrument note number
mm: 00H-7FH (0...127)
O
( Drum only )
XOXXXXXOOXOXX
1EH rrH mmH -- Drum Chorus Send Level rr: drum instrument note number
mm: 00H-7FH (0...127)
O
( Drum only )
XOXXXXXOOXOXX
1FH rrH mmH -- Drum Variation Send Level rr: drum instrument note number
mm: 00H-7FH (0...127)
(Variation Connection=SYSTEM)
mm: 00H, 01H-7FH (OFF, ON)
(Variation Connection=INSERTION)
O
( Drum only )
XOXXXXXOOXOXX
30H rrH mmH -- Drum EQ Bass Gain rr: drum instrument note number
mm: 00H-7FH (0...127)
XXXXXXXXXXXXXX
31H rrH mmH -- Drum EQ Treble Gain rr: drum instrument note number
mm: 00H-7FH (0...127)
XXXXXXXXXXXXXX
34H rrH mmH -- Drum EQ Bass Frequency rr: drum instrument note number
mm: 04H-28H (32...2.0k[Hz])
XXXXXXXXXXXXXX
35H rrH mmH -- Drum EQ Treble Frequency rr: drum instrument note number
mm: 1CH-3AH (500...16.0k[Hz])
XXXXXXXXXXXXXX
NRPN Data Entry Parameter Data Range Voice MIDI Reception MIDI Transmission PLAY REC
MSB LSB MSB LSB Regular/Drum/
Natural/Organ
Voice
Mic/Vocal
Harmony
Song Right1/
Right2/
Left
Keyboard Style Extra Right1/
Right2/
Left
Style Song Upper
Lower
PLAY REW From
panel
(Right1/
Right2/
Left)
00H 00H mmH -- Harmony Mute mm: 00H-3FH, 40H-7FH (Off, On) X O
(Harmony
Channel)
XX X XXXXO XOX X
01H 1AH mmH -- Detune Modulation mm: 00H-7FH (0...127) X O
(Harmony
Channel)
XX X XXXXO XOX X
02H 10H mmH -- Harmony1 Volume mm: 00H-7FH (0...127) X O
(Harmony
Channel)
XX X XXXX
● XOX X
02H 11H mmH -- Harmony2 Volume mm: 00H-7FH (0...127) X O
(Harmony
Channel)
XX X XXXX
● XOX X
02H 12H mmH -- Harmony3 Volume mm: 00H-7FH (0...127) X O
(Harmony
Channel)
XX X XXXX
● XOX X
02H 20H mmH -- Harmony1 Pan mm: 00H, 01H-40H-7FH
(RND, L63...C...R63)
XO
(Harmony
Channel)
XX X XXXX ● XOX X
02H 21H mmH -- Harmony2 Pan mm: 00H, 01H-40H-7FH
(RND, L63...C...R63)
XO
(Harmony
Channel)
XX X XXXX ● XOX X
02H 22H mmH -- Harmony3 Pan mm: 00H, 01H-40H-7FH
(RND, L63...C...R63)
XO
(Harmony
Channel)
XX X XXXX ● XOX X
02H 30H mmH -- Harmony1 Detune mm: 00H-40H-7FH (-64...0...+63) X O
(Harmony
Channel)
XX X XXXX ● XOX X
02H 31H mmH -- Harmony2 Detune mm: 00H-40H-7FH (-64...0...+63) X O
(Harmony
Channel)
XX X XXXX ● XOX X
02H 32H mmH -- Harmony3 Detune mm: 00H-40H-7FH (-64...0...+63) X O
(Harmony
Channel)
XX X XXXX ● XOX X
