Instrument operation
82
System control screen
The system control screen can be used to
turn the boat lights, blowers, and bilge pump
on and off.
When a light is turned on, it will be indicated
on the illustration of the boat displayed on the
screen.
To adjust the brightness of the courtesy
lights:
Use the slider control to adjust the brightness
of the courtesy lights.
1 Slider control
The brightness can also be adjusted by tap-
ping the “ ” or “ ” button.
Ballast setting screen (212X)
This boat is equipped with an adjustable bal-
last system to increase the amount of wake
the boat leaves behind it. The more water that
is pumped into the ballast bag and ballast
tanks, the bigger the boat’s wake.
Improper use of the ballast system can
overload the boat, causing poor han-
dling and increased risk of swamping.
The ballast system adds 591 kg (1303 lb)
when full. Include this weight when
making sure your load does not exceed
the weight shown on the maximum ca-
pacities label.
Drain the ballast completely before
trailering the boat to reduce the risk of a
towing accident. The increased weight
of ballast can cause unsafe towing con-
ditions due to negative tongue weight,
including decreased tow vehicle stabili-
ty and greater chance of a runaway trail-
er that has come off the hitch.
Item Function
Turns the docking lights on
or off.
Turns the courtesy lights
on or off. The slider indi-
cates the brightness of the
lights while they are turned
on.
Turns the anchor light and
bow light on or off.
Turns the anchor light on
or off. If this button is
tapped while the naviga-
tion lights are turned on,
the bow light will turn off.
Turns the blowers on or off.
(See page 139.)
Displays the ballast set-
ting screen.
Turns the bilge pump on or
off. (See page 127.)
Dock
Interior
Navigation
Anchor
Ballast
Blower
Bilge
Dock
Interior
Blower
Ballast
Bilge
