Yamaha Disklavier DGP1 - Page 57

II-5
<Fig. 3> Rear Side of Bass Bracket
<Fig. 4>
Stopper
Stay
Screws
Stopper rubber
Stopper bolt
Lock screws
Screw
Stopper pivot
(Inserted into the stopper pivot hole)
<Fig. 5>
Gap 0.1–0.5 mm
Stopper pivot hole.
