Yamaha diversion 900 XJ900S User Manual

6
PERIODIC MAINTENANCE AND MINOR REPAIR
Owner’s tool kit ....................................................6-1
Periodic maintenance and lubrication chart .........6-2
Removing and installing cowlings ........................6-5
Checking the spark plugs ....................................6-7
Engine oil and oil filter cartridge ..........................6-8
Final gear oil ......................................................6-11
Cleaning the air filter element ............................6-13
Adjusting the carburetors ...................................6-15
Adjusting the engine idling speed ......................6-15
Adjusting the throttle cable free play ..................6-16
Adjusting the valve clearance ............................6-16
Tires ...................................................................6-17
Cast wheels .......................................................6-20
Adjusting the clutch lever free play ....................6-20
Adjusting the brake pedal position .....................6-21
Adjusting the rear brake light switch ..................6-21
Checking the front and rear brake pads .............6-22
Checking the brake fluid level ............................6-23
Changing the brake fluid ....................................6-24
Checking and lubricating the cables ..................6-24
Checking and lubricating the throttle grip and
cable ............................................................... 6-24
Checking and lubricating the brake and
shift pedals ...................................................... 6-25
Checking and lubricating the brake and
clutch levers .................................................... 6-25
Checking and lubricating the centerstand and
sidestand ......................................................... 6-25
Lubricating the rear suspension ........................ 6-26
Checking the front fork ...................................... 6-27
Checking the steering ....................................... 6-27
Checking the wheel bearings ............................ 6-28
Battery ............................................................... 6-29
Replacing the fuses .......................................... 6-30
Replacing the headlight bulb ............................. 6-31
Replacing the tail/brake light bulb ..................... 6-32
Replacing a turn signal light bulb ...................... 6-32
Front wheel ....................................................... 6-33
Rear wheel ........................................................ 6-35
Troubleshooting ................................................. 6-37
Troubleshooting chart ........................................ 6-38
E_4km.book Page 1 Tuesday, August 28, 2001 9:51 AM

Yamaha diversion 900 XJ900S Specifications

General

Displacement	892 cc
Compression Ratio	10.0:1
Ignition	TCI (Transistor Controlled Ignition)
Transmission	5-speed
Final Drive	Shaft
Frame	Steel, double cradle
Front Suspension	Telescopic fork
Rear Brakes	Single disc
Rear Tire	150/70-17
Engine Type	4-stroke, DOHC, inline-4
Bore x Stroke	68.5 mm x 60.5 mm
Fuel System	Carburetor
Rear Suspension	Monoshock
Front Brakes	Dual disc
Front Tire	120/70-17
Fuel Capacity	24 liters
