5-2. VOICE PARAMETERS (VCED format)
Parameter no.
P
Parameter
LCD Display
Data
Note
0
ATTACK RATE
EG AR
0 ~31
1
DECAY 1 RATE
EG D1R
0 ~31
2 DECAY 2 RATE
EG D2R
0 ~31
3 RELEASE RATE
EG RR
0 ~15
4
DECAY 1 LEVEL
EG D1L
0 ~15
5 KEYBOARD SCALING LEVEL LEVEL SCALE
0~99
6
KEYBOARD SCALING RATE OP4
RATE SCALE
0~3
7
EG BIAS SENSITIVITY
E BIAS SENS.
0~7
8
AMPLITUDE MODULATION ENABLE
A MOD SENS.
0,1
9 KEY VELOCITY
KEY VELOCITY
0~7
10 OUTPUT LEVEL
OUTPUT LEVEL
0~99
11
OSCILLATOR FREQUENCY
FREQUENCY
0~63
12
DETUNE 1
DETUNE
0~7
13
SAME AS FOR OP4
OP2
25
26
SAME AS FOR OP4
OP3
38
39
SAME AS FOR OF4
OP1
51
52 ALGORITHM
ALGORITHM SELECT
0~7
53 FEEDBACK LEVEL
FEEDBACK
0~7
54 LFO SPEED
LFO SPEED
0~99
55 LFO DELAY
LFO DELAY
0~99
56 PITCH MODULATION DEPTH
LFOPMD
0~99
57 AMPLITUDE MODULATION DEPTH
LFO AMD
0~99
58 LFO SYNC
LFO SYNC
0,1
59 LFO WAVE
LFO WAVE
0~3
60 PETCH MODULATION SENSITIVITY
P MOD SENS.
0 ~ 7
61
AMPLITUDE MODULATION SENSITIVITY A MOD SENS. 0~7
62 TRANSPOSE
Middle C
0 ~ 48
63
PLAY MODE POLY/MONO Poly Mode
0, 1
64
PITCH BEND RANGE P Bend Range
0 ~ 12
65 PORTAMENTO MODE
Full Time Porta
0,1
66 PORTAMENTO TIME
Porta Time
0~99
67 FOOT VOLUME
Foot Volume
0~99
68 SUSTAIN FOOT SWITCH
FootSustain
0,1
69 PORTAMENTO FOOT SWITCH
Foot Porta
0,1
70 CHORUS SWITCH
Chorus
0,1
71 MODULATION WHEEL PITCH MODULATION RANGE
MW Pitch
0~99
72 MODULATION WHEEL AMPLITUDE MODULATION RANGE
MW Amplitude 0~99
73 BREATH CONTROL PITCH MODULATION RANGE
BC Pitch
0~99
74 BREATH CONTROL AMPLITUDE MODULATION RANGE
BC Amplitude
0 ~99
75 BREATH CONTROL PITCH BIAS RANGE
BC PitchBias
0 ~99
76 BREATH CONTROL EG BIAS RANGE
BC EG Bias
0~99
77
VOICE NAME
1 ASCII
86
10~99
87
PITCH EG RATE 1 PEG RATE 1
0 ~99
88 PITCH EG RATE 2
PEG RATE
2
0 ~99
89 PITCH EG RATE 3
PEG RATE
3
0 ~99
90 PITCH EG LEVEL 1
LEVEL 1
0 ~99
91
PITCH EG LEVEL 2
LEVEL 2
0 ~99
92
PITCH EG LEVEL 3
LEVEL 3
0~99
