8-17
DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
SQUARE STYLE GAUGE RIGGING KIT FOR EUROPE
TWIN KIT (TACH, TACH, SPEED, FUEL MGT) w/o Transom Wire Harness
Kit P/N: 6Y8-W0035-30
Part No. Part Name Q’ty Remarks
6Y8-82553-01 Main bus wire, 1 ft 1
6Y8-82521-11 Pigtail bus wire, 2 ft 4
6Y8-81920-01 Multi-hub 2 With resistor cap, GRY
6Y8-82582-01 2-pin cap, RED 1 For waterproof
6Y8-82582-11 4-pin cap, WHT 2 For waterproof
6Y8-8350T-01 SQR tachometer 2
6Y8-8350S-01 SQR speedometer 1
6Y8-8350F-01 SQR fuel mgt gauge 1
6Y8-8356N-01 Fuel tank & GPS wire 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
6Y8-2819U-70 Operation manual 1 1
6Y8-2819U-80 Operation manual 2 1
6Y8-2819K-S1 Quick installation guide 1
6Y8-2819U-X0 Quick operation guide 1
