Yamaha FX-310 - Parts List

FX-310
2
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
: New Parts RANK : Japan only
PARTS LIST
*
*
*
OVERALL ASSEMBLY FX-310 (SYSTEM42)
01 Pickup CP-102
02 Amplifier Assembly DJ2B with YAMAHA PANEL 08
02a Knob DJ2B TONE, GAIN 2 01
02b Flat Head Screw 2.5X15 BL 4
03 Endpin Jack 07
03a Round Head Wood Screw 2.0X10 FNM33G (NI) 3
04 Sticker P-20 02
QC457500
QC413100
CX816150
EX803920
QC403000
EX803930
VC668400
03a
01
03
02b02a
02 04
BLACK LONG
WHITE SHORT
