Features and functions
43
EJU35010
“L-MODE” indicator light
The “L-MODE” indicator light comes on when
the low-RPM mode is selected. (See page 39
for more information.)
EJU35020
Left multifunction display and operation
buttons
The left multifunction display is equipped with
the following functions.
The following operation buttons are on the left
side of the multifunction meter.
EJU35041
Digital speedometer
The digital speedometer shows the watercraft
speed against water.
NOTE:
● To switch the speedometer display be-
tween kilometers and miles, push the
“Volt/Hour” button for at least 1 second,
within 10 seconds after the multifunction
meter starts operating.
● The “SPEED” indicator light blinks three
times if miles are selected as the display
units when the multifunction meter starts
1 “L-MODE” indicator light
1 Fuel level meter
2 Fuel level warning indicator
3 Hour meter/voltmeter
4 Digital speedometer
5 Oil pressure warning indicator
6 Check engine warning indicator
7 Engine overheat warning indicator
1 “Speed/RPM” button
2 “Volt/Hour” button
1 Digital speedometer
UF1X11E0.book Page 43 Monday, August 7, 2006 3:51 PM
