SPECIFICATIONS
1
2
3
4
5
6
7
8
9
10
11
10-3
UTILITY
CHASSIS
Items G11A
Steering system:
Type Worm and pin
Steering angle (L.H.) 1.5 turn
Steering angle (R.H.) 1.5 turn
Lubricant/capacity Grease/3.0 US oz (0.09 L, 3.17 Imp oz)
Brakes:
Brake system Mechanical drum brake on each rear wheel
with self-adjusters.
Type of brake Dual internal expanding shoe.
Leading/trailing shoes (self-adjusting)
Brake pedal freeplay linkage
adjustment 25-30 mm
(Brake cable end play) 0.004-0.02 in. (0.1-0.5 mm)
Parking brake:
Type Foot type; parking brake with automatic
release.
Release timing
(Bolt heads round parallel to arm) 0.04 in. (1 mm)
Wheel:
Tire size:
Front 18 x 8.50–8.00/4 PR
Rear 18 x 8.50–8.00/TURF
Rim size: 7.00–I–8.00
Tire pressure: For G11A:
20 - 23 psi (140 - 160 kPa, 1.4 - 1.6 kgf/cm
2
)
