Yamaha MOTIF ES6 Software Guide

15
2.3. 01X + DAW incompatible with OPT or Total Recall + Multi Part Editor + MOTIF ES
The ports other than those assigned for 01X remote control can be changed.
mLAN Remote MIDI In/Out Port 5mLAN Remote MIDI In/Out Port 1
DAW
Audio Mixer
Track View
Multi Part
Editor
Studio Manager
Controller: 01X
MOTIF ES6/7/8
Merge (join) Port 0-1
with Port 0-2
USB MIDI In/Out Port 0-1
USB MIDI In/Out Port 0-1
USB MIDI In/Out Port 0-2
(page 8)

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
