Yamaha Pacifica 112J - Circuit Diagram; Wiring Diagram

Pacifica 112J/Pacifica 112XJ
4
WIRINGCIRCUIT DIAGRAM
FRONT PICKUP
CENTER PICKUP
REAR PICKUP
TONE VOLUME OUTPUT
05A 250KΩ
15A 500KΩ
1
2
3
1
2
3
(2pole 5position)
PICKUP SWITCH
0.022uF
GP12-03
FRONT
PICKUP
CENTER
PICKUP
REAR
PICKUP
to spring plate
RE
RE
RE
BL
OUTPUT
JACK
BL
VOLUME
15A 500KΩ
0.022uF
TONE
05A 250KΩ
PICKUP
SWITCH
*
REF NO.
PART NO. DESCRIPTION REMARKS
QTY
RANK
: New Parts RANK: Japan only
P02e Knob White Pacifica112J 02
P02e Knob Black Pacifica112XJ (with PU SW) 02
P02f Oval Head Screw 3.0X8 FNM33G (Nickel) with Pickup Switch 2
P02g Hexagonal Nut M8 t=2 with Volume 4
P02h Flat Washer 8 t=0.5 with Volume 2
P02i Toothed Lock Washer 10 t=0.5 with Volume 2
P03 Volume Knob KPK6D2S1H-B (White) Pacifica112J 04
P03 Volume Knob ST-type (Black) Pacifica112XJ 06
P04 Tone Knob KPK6D2S1H-A (White) Pacifica112J 04
P04 Tone Knob ST-type (Black) Pacifica112XJ 06
P05 Pickup Assembly S/C KEU9DE6000S (WH) FRONT/Pacifica112J 11
P05 Pickup Assembly S/C Taiwanese (BL) FRONT/Pacifica112XJ 09
P06 Pickup Spring 5X7.5X18 A 2
P07 Oval Head Screw 3.0X25 FNM33G Nickel 2
P08 Pickup Assembly S/C KEU9DE6000N (WH) CENTER/Pacifica112J 11
P08 Pickup Assembly S/C Taiwanese (BL) CENTER/Pacifica112XJ 09
P09 Pickup Spring 5X7.5X18 A 2
P10 Oval Head Screw 3.0X25 FNM33G Nickel 2
P11 Pickup Assembly H/B 403H (White) REAR/Pacifica112J
P11 Pickup Assembly H/B Taiwanese (BL) REAR/Pacifica112XJ 09
P12 Pickup Spring 5X30 B 2
P13 Oval Head Screw 3.0X30 FNM33G Nickel 2
CB807510
CB821810
QC562000
--
--
--
QC562400
QC587000
QC562500
QC587100
QC561100
QC166900
QC561200
QC561300
QC561400
QC163800
QC561200
QC561300
QC675400
QC288700
QC561600
QC561700
